SMEG Range SPR - Stainless Steel (SPR48UGMX)

Product Features

Product Specifications

General information

Product family	Range
Range size	48"
Range type	Dual fuel
Installation positioning of the appliance	Free-standing, Class 1
Cooktop	Mixed
N. of ovens	2
Main oven	Thermo-ventilated
Secondary oven	Thermo-ventilated
EAN code	8017709348465

Aesthetic

Color	Stainless steel
Design	Squared design
Finishing	Satin
Aesthetics	SPR
Material	Stainless steel
Cooktop color	Stainless steel
Grates	Cast Iron
Control setting type	Control knobs
No. of controls	10
Display	Touch
Handle	Robust knurled handle
Storage compartment	Drawer
Plinth	Black

Main oven options

Timer	Yes
End-of-cooking alarm	Yes
Minimum Temperature	120 °F
Maximum temperature	500 °F

Secondary oven functions

Minimum Temperature	120 °F
Maximum temperature	450 °F

Cooktop technical features

Cooking zones	6
Zone 1 - Power	22000 BTU
Zone 2 - Power	15000 BTU
Zone 3 - Power	5000 BTU
Zone 4 - Power	1400 W
Zone 5 - Power	3500 W
Zone 6 - Power	8000 BTU
Burner caps	Enameled matte black
Gas safety valves	Yes

Main Oven Technical Features

Volume	4.45 cu. ft.
Cavity material	EverClean enamel
No. of shelves	5
Shelves type	Metal racks
No. of lights	2
Light type	Halogen
Light Power	40 W
Fan number	2
Time setting	Start and end
Light on when door is open	Yes
Removable door	Yes
Total no. of door glasses	3
Safety thermostat	Yes
Cooling system	Tangential
Grill type	Electric
Grill power	1700 W
Large grill - Power	2900 W
Bottom heating element - Power	1700 W
Upper heating element - Power	1200 W
Circular heating element - Power	1500 W
Soft Close system	Yes

Secondary oven - Technical specifications

Cavity material	EverClean enamel
No. of shelves	5
Shelves type	Metal racks
No. of lights	2
Lighting	Halogen
Light Power	40 W
Fan number	1
Light on when oven door is open	Yes
Removable door	Yes
No. total door glasses	3
Security Thermostat	Yes
Cooling system	Tangential
Large grill - Power	2050 W
Lower heating element - power	750 W
Soft Close	Yes

Electrical Connection

Plug	(B) NEMA 14-50P
Electrical connection rating	8500 W
Current	35 A
Circuit breaker	40 A
Voltage	208/240 V
Frequency	60 Hz
Power cord length	47 1/4 "
Type of electric cable installed	Yes, Double phase

Gas Connection

Gas Type

G20 Natural gas

Logistic Information

Dimensions	900x1200x600 mm
Width	47 1/4 "
Height	35 7/16 "
Depth	23 5/8 "
Packaged dimensions	1060X1280X735 mm
Gross weight	412 lbs
Net weight	339 lbs
Packaged width	50 3/8 "
Packaged depth	28 15/16 "
Packaged height	41 3/4 "
Maximum stackability	2
Packaging	Cardboard box
Packaging composition - Paper	13 lbs
Packaging composition - Polystyrene	5 lbs
Packaging composition - Wood	54 lbs
Packaging composition - Plastics	1 lbs
