SUMMIT 24" Wide Built-In Coffee Kegerator, ADA Compliant - Panel-Ready (SBC58BLBIADAIFCMTWIN)
SKU:
SBC58BLBIADAIFCMTWIN
Regular price
$3,110.00
Unit price
/
Unavailable
SUMMIT 24" Wide Built-In Coffee Kegerator, ADA Compliant - Panel-Ready (SBC58BLBIADAIFCMTWIN) is available for ordering but may require additional time to be fulfilled. Please contact us for details.
Delivery and Shipping
Delivery and Shipping
Local deliveries available in LA, Orange, San Bernardino & Riverside counties in California. Please contact us if you are outside of our service areas.
Key Features
- ✔ ADA compliant height
- ✔ Dispenses both flat and nitro coffee
- ✔ Commercially approved
- ✔ Dual tap system
- ✔ Panel-ready door
- ✔ Adjustable thermostat
- ✔ Built-in capable
- ✔ Complete tap kit
- ✔ Automatic defrost
- ✔ User-reversible door
- ✔ Stainless steel drip tray
- ✔ Stainless steel guard rail
- ✔ Interior light
- ✔ Interior nitrogen tank holder
- ✔ Stainless steel floor cover
- ✔ One piece interior liner
- ✔ Hidden evaporator
- ✔ Fully finished cabinet
- ✔ 100% CFC free
- ✔ CARB Compliant
Documents
SUMMIT 24" Wide Built-In Coffee Kegerator, ADA Compliant - Pan...
Regular price
$3,110.00
Unit price
/
Unavailable
Product Features
ADA compliant height
Sized at 32 inches high (32.25 to hinge cap) for installation under lower ADA compliant counters
Dispenses both flat and nitro coffee
Unique combination stout and standard tap system allows you to serve both flat iced cold brew and nitro drafts
Commercially approved
ETL-S listed to NSF-7 commercial standards and meets UL-471 for use in foodservice settings
Dual tap system
Twin style draft tower allows you to serve from two cornelius style kegs
Panel-ready door
Customize the front by mounting an overlay panel over the door; seamless look can blend into other cabinetry with no exposed frame. Handle not included (panel size: 23 5/16" W x 28 1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
Adjustable thermostat
Interior dial thermostat ensures easy temperature management
Built-in capable
Front-breathing design lets you make the best use of space by installing your appliance under the counter
Complete tap kit
Commercial grade tap kit includes a dual tap draft tower with a standard and stout tap, Nitrogen tank, dual gauge regulator, and connections for ball lock Cornelius kegs
Automatic defrost
No-frost operation for minimum user maintenance
User-reversible door
Unit ships with a right hand door swing. For a left hand version, add option LHD upon order
Stainless steel drip tray
Removable two-piece drip tray included for added convenience
Stainless steel guard rail
Durable railing makes it easier to neaten service
Interior light
Turn the light on when you need it and off when you're done with a convenient rocker switch
Interior nitrogen tank holder
Bracket is installed inside, allowing you to save on depth by keeping the tank behind your kegs
Stainless steel floor cover
Interior includes steel cover to protect the floor when loading kegs
One piece interior liner
Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
Hidden evaporator
Cold wall design with hidden evaporator and seamless interior
Fully finished cabinet
Allows the unit to be used freestanding
100% CFC free
Environmentally friendly design without ozone-damaging chemicals
CARB Compliant
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Product Specifications
Overview
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.25" (82 cm) |
| Width | 23.63" (60 cm) |
| Depth | 22.75" (58 cm) |
| Depth with door at 90° | 45.0" (114 cm) |
| Capacity | 5.5 cu.ft. (156 L) |
| Defrost Type | Automatic |
| Door | Panel-Ready |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Amps | 1.2 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 110.0 lbs. (50 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101069678 |
Kegerator
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Tap Kit | Yes |
| Number of Taps | 2 |
| Thermostat Type | Dial |
| Interior Light | Yes |
| Fan Type | Exterior |
| Refrigerant | R600a |
| Refrigerant Amount | 0.64 oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Inter Height | 25.75" (65 cm) |
| Interior Width | 21.0" (53 cm) |
| Interior Depth | 17.75" (45 cm) |
| Compressor Step Height | 6.5" (17 cm) |
| Compressor Step Width | 21.0" (53 cm) |
| Compressor Step Depth | 5.5" (14 cm) |
| Temperature Range | 34 to 43F |
Warranty
| Parts | 1 Year |
| Labor | 1 Year |
Dimensions & Weight
| Width | 23.63 in. |
| Height | 32 in. |
| Length | 22.75 in. |
| Weight | 110 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 28.63 in. |
| Shipping Height | 37 in. |
| Shipping Length | 27.75 in. |
| Shipping Weight | 150 lbs. |
| Total of Shipping Weight | 150 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 9.96 ft |
| Dimensional Weight | 123.76 lbs. |
| Total of Cubes | 9.96 ft |
| Total of Dimensional Weight | 123.76 lbs. |
Certifications
California Prop 65
